Three Head Research Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-TAMHM-11171
Quick Answer: The Three Head Research Microscope lets 3 observers view at once through a discussion attachment with 2 extra binocular heads and an LED pointer, with objectives from 2x to 100x.
Last updated: October 2026
Key Features
- Discussion attachment for 3 simultaneous observers, with LED pointer arrow
- 2 binocular heads with WF10x/20 mm eyepieces besides the main head
- Main trinocular head, 30°, with 100/0, 50/50 and 0/100 positions
- Sextuple reversed nosepiece for RMS objectives with DIC slot; objectives 2x to 100x
- Swing-out condenser options: 0.90/0.25 NA, 1.20 NA or 0.90 NA
- Stage options include rackless, mineral solid surface and a heating stage with digital controller
Technical Specifications
| Specification | Value |
|---|---|
| Objectives | 2x, 4x, 10x, 20x, 40x, 60x, 100x |
| Main head | Trinocular, 30°, 100/0, 50/50, 0/100 |
| Observers | 3, with LED pointer |
| Illumination | 8W white LED, 6300K, approx. 50,000h |
| Power supply | Input 100-240Vac 50-60Hz, output 6Vdc 2.5A, max 13W |
| Focusing | Coaxial coarse and fine, graduated 0.002mm, upper stop, adjustable tension |
About This Product
This research microscope is set up for group viewing, with a multi-viewing device that serves three observers at the same time and an LED arrow under the main head to point out features. Its main body carries the focus system and a white LED light source with an intensity knob on the left of the frame. Condenser and stage can be chosen from several types, including a heating stage with a digital temperature controller.
Frequently Asked Questions
How many people can use the Three Head Research Microscope at once?
Three observers can view simultaneously through the multi-viewing device.
Which objectives are available?
2x, 4x, 10x, 20x, 40x, 60x and 100x.
Related: Teaching and Multi Head Microscope, Two Head Pathology Microscope, Side by Side and Binocular LED Dual View Teaching Microscope.
For a quotation on the Three Head Research Microscope, contact Didactic Lab.
