Demonstration Dynamo Model Manufacturer,Supplier and Exporter in India

Demonstration Dynamo Model

Product Code : EL-ET-10657

Quick Answer: The Demonstration Dynamo Model is a hand-driven dynamo on a 230 x 90mm base plate, with a 120mm hand-drive pulley belted to a smaller dynamo pulley for a step-up ratio.

Last updated: October 2026

Key Features

  • Same basic assembly as the Demonstration Electric Motor
  • Base plate of 230 x 90mm
  • Hand-drive pulley of 120mm diameter coupled by a rubber belt to a smaller dynamo pulley
  • Electrical output via a pair of 4mm sockets, with a lamp as an output indicator
  • Can also be used as a motor on a 6-8V DC supply

Technical Specifications

SpecificationValue
Base plate230 x 90mm
Hand-drive pulley120mm diameter
DriveRubber belt, step-up ratio
OutputPair of 4mm sockets
IndicatorLamp
Motor use6-8V DC

About This Product

This model takes the assembly of the Demonstration Electric Motor and mounts it on a base plate with a large hand-drive pulley. Turning the pulley drives the smaller dynamo pulley through a rubber belt, and a lamp gives a simple indication of the output at the 4mm sockets. Supplied with 6-8V DC, the model can also run as a motor.

Frequently Asked Questions

Can the dynamo model be used as a motor?

Yes, it may also be used as a motor on a 6-8V DC supply.

How is the output shown?

Electrical output is via a pair of 4mm sockets, and a lamp is provided as a simple output indicator.

Related: Energy Transfer, Water Turbine with Dynamo Model and Demonstration Motor AC/DC.

For a quotation on the Demonstration Dynamo Model, contact Didactic Lab.
