Electron Diffraction Tube D Manufacturer,Supplier and Exporter in India
Product Code : EL-AANP-10620
Quick Answer: The Electron Diffraction Tube D is a highly evacuated electron tube that demonstrates the wave nature of electrons by Debye-Scherrer diffraction through a polycrystalline graphite lattice, shown on a fluorescent screen.
Last updated: October 2026
Key Features
- Highly evacuated tube with a fluorescent screen
- Shows interference of electrons passing through a polycrystalline graphite lattice
- Used to find wavelength as a function of anode voltage from the diffraction ring radii
- D range tube with connections fixed on the tube
- Maximum anode voltage 5 kV; anode current approx. 0.1 mA at 4 kV
- Instructions included
Technical Specifications
| Specification | Value |
|---|---|
| Max. anode voltage | 5 kV |
| Anode current | Approx. 0.1 mA at 4 kV |
| Max. filament voltage | 6.3 V AC |
| Graphite lattice constant d10 | 0.213 nm |
| Graphite lattice constant d11 | 0.123 nm |
| Connections | Fixed on the tube (D range) |
About This Product
Electrons passing through a polycrystalline graphite lattice produce diffraction rings on the fluorescent screen, showing their wave nature. From the radii of the rings and the lattice plane spacing of graphite, students can determine the wavelength as a function of anode voltage and confirm de Broglie's hypothesis. This is a D range tube with its connections fixed on the tube, so it is not interchangeable with the S range, which has connections on the stand. The Electron Diffraction Tube D is offered to export buyers in Trinidad and Tobago, Poland, Latvia, Mali, Saint Vincent and the Grenadines and Palestine.
Frequently Asked Questions
What is the difference between the D and S ranges?
D range tubes have their connections fixed on the tube, while the newer S range has connections on the stand. The two ranges are not interchangeable.
What anode voltage does the tube take?
The maximum anode voltage is 5 kV, with an anode current of approx. 0.1 mA at 4 kV. The maximum filament voltage is 6.3 V AC.
What can be measured with the tube?
The wavelength as a function of anode voltage, from the radii of the diffraction rings and the lattice plane spacing of graphite, which also confirms de Broglie's hypothesis.
