Double Beam Balance Manufacturer,Supplier and Exporter in India
Product Code : EL-LB-10834
Quick Answer: The Double Beam Balance is a two pan balance that weighs up to 210 gm on its two beams, with supplementary masses extending the range to 2 kg.
Last updated: October 2026
Key Features
- Two beams with centre reading sliding masses
- Beam ranges of 0-200 gm x 10 gm and 0-10 gm x 0.1 gm, total 210 gm
- Supplementary masses extend the range to 2 kg
- Spring loaded zero adjuster
- Magnetic damping
- Stainless steel pans of 150 mm diameter
Technical Specifications
| Specification | Value |
|---|---|
| Beam ranges | 0-200 gm x 10 gm and 0-10 gm x 0.1 gm |
| Total on beams | 210 gm |
| Extended range | 2 kg with supplementary masses |
| Pans | Two, stainless steel, 150 mm diameter |
| Zero adjustment | Spring loaded |
| Damping | Magnetic |
About This Product
This balance has two pans and two beams fitted with centre reading sliding masses. One beam reads 0 to 200 gm in 10 gm steps and the other 0 to 10 gm in 0.1 gm steps. Adding supplementary masses takes the range up to 2 kg, and the instrument has a spring loaded zero adjuster and magnetic damping.
Frequently Asked Questions
How much can it weigh?
The beams give a total of 210 gm, and supplementary masses extend the range to 2 kg.
What are the pans made of?
The two pans are stainless steel with a diameter of 150 mm.
Related: Laboratory Balances, Triple Beam Balance and Analytical Balance.
For a quotation on the Double Beam Balance, contact Didactic Lab.
